C. R. Laurence
CRL Wet Glaze 1¨and 1-1/2" Deep U-Channel 120" Stock Length
CRL Wet Glaze 1¨and 1-1/2" Deep U-Channel 120" Stock Length
Couldn't load pickup availability
CRL Wet/Dry Glaze U-Channels
Combine the Deep U-Channel on the top with the Shallow U-Channel at the bottom for a "lift and drop" glazing method. Secure glass with silicone sealant or a top-load roll-in gasket.
Both models are compatible with 3/8" (10 mm) and 1/2" (12 mm) monolithic tempered glass.
Shallow U-Channel – 1" Height
- Finish/Color: Brite Anodized
- Glazing Thickness: 3/8 in. or 1/2 in. (10 mm or 12 mm)
- Height: 1 in. (25 mm)
- Width: 1 in. (25 mm)
- Length: 120 in. (3048 mm)
This CRL Shallow U-Channel provides a minimal profile and is commonly used at the base of glass panels in railing or partition applications. Designed for monolithic tempered glass, compatible with both 10 mm and 12 mm thicknesses, and can be sealed with silicone or a dry glazing gasket.
Deep U-Channel – 1-1/2" Height
- Finish/Color: Brite Anodized
- Glazing Thickness: 3/8 in. or 1/2 in. (10 mm or 12 mm)
- Height: 1-1/2 in. (38 mm)
- Width: 1 in. (25 mm)
- Length: 120 in. (3048 mm)
The Deep U-Channel is ideal for top-edge glazing of heavier glass. It allows for deeper insertion for additional stability and is suitable for both wet (silicone) and dry (gasket) installations. Supports both 10 mm and 12 mm monolithic tempered glass panels.
This model is stocked in centralized service centers for fast resupply. Check availability using the “CHECK STOCK AVAILABILITY” option during ordering.
Comparison Table
| Specification | Shallow U-Channel (1" Height) |
Deep U-Channel (1-1/2" Height) |
|---|---|---|
| Finish/Color | Brite Anodized | Brite Anodized |
| Glazing Thickness | 10 mm or 12 mm | 10 mm or 12 mm |
| Height | 1 in. (25 mm) | 1-1/2 in. (38 mm) |
| Width | 1 in. (25 mm) | 1 in. (25 mm) |
| Length | 120 in. (3048 mm) | 120 in. (3048 mm) |
| Installation Use | Bottom of glass panels | Top of glass panels |
| Glass Type | Monolithic tempered | Monolithic tempered |
| Sealing Method | Silicone or Glazing Gasket | Silicone or Glazing Gasket |
