Richelieu Riveo Square Wall Mount Hinge with H Backplate – Pair
Richelieu Riveo Square Wall Mount Hinge with H Backplate – Pair - Chrome est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Description
Description
Richelieu Riveo Square Wall Mount Hinge with H Backplate – Pair – Chrome +–
Richelieu Riveo Square Wall Mount Hinge with H Backplate – Pair – Chrome
Product Overview
This Riveo square hinge connects a tempered glass shower door to an adjacent wall using an H-shaped backplate. Its self-closing mechanism engages from 15°. Each sales unit contains two hinges.
Product Features
- Square profile with a h-shaped backplate
- Self-closing from 15°
- Designed for 8–10 mm tempered glass
- Sold as one pair containing two hinges
Product Specifications
| Product Number | SH3SQ90HW140 |
|---|---|
| Finish | Chrome |
| Brand / Series | Riveo |
| Mounting Method | Wall Mount (Glass-to-Wall) |
| Backplate | H-shaped |
| Angle | 90° |
| Self-Closing | From 15° |
| Glass Thickness | 8–10 mm |
| Glass Type | Tempered |
| Material | Solid brass with stainless steel pin and spring |
| Duty | Regular-Duty |
| Maximum Door Weight — 2 Hinges | 35 kg |
| Maximum Door Weight — 3 Hinges | 54 kg |
| Maximum Door Width — 2 Hinges | 31" |
| Sales Unit | Pair (2 hinges) |
Installation Notes
Glass requires mouse-ear preparation. Confirm the manufacturer's drawing and installation requirements before fabricating the glass.
Manufacturer image is representative; finish varies with selection.
Technical Documents
Richelieu Riveo Square Wall Mount Hinge with H Backplate – Pair – Matte Black +–
Richelieu Riveo Square Wall Mount Hinge with H Backplate – Pair – Matte Black
Product Overview
This Riveo square hinge connects a tempered glass shower door to an adjacent wall using an H-shaped backplate. Its self-closing mechanism engages from 15°. Each sales unit contains two hinges.
Product Features
- Square profile with a h-shaped backplate
- Self-closing from 15°
- Designed for 8–10 mm tempered glass
- Sold as one pair containing two hinges
Product Specifications
| Product Number | SH3SQ90HW900 |
|---|---|
| Finish | Matte Black |
| Brand / Series | Riveo |
| Mounting Method | Wall Mount (Glass-to-Wall) |
| Backplate | H-shaped |
| Angle | 90° |
| Self-Closing | From 15° |
| Glass Thickness | 8–10 mm |
| Glass Type | Tempered |
| Material | Solid brass with stainless steel pin and spring |
| Duty | Regular-Duty |
| Maximum Door Weight — 2 Hinges | 35 kg |
| Maximum Door Weight — 3 Hinges | 54 kg |
| Maximum Door Width — 2 Hinges | 31" |
| Sales Unit | Pair (2 hinges) |
Installation Notes
Glass requires mouse-ear preparation. Confirm the manufacturer's drawing and installation requirements before fabricating the glass.
Manufacturer image is representative; finish varies with selection.
Technical Documents
